Description
General
| Model | T786x |
|---|---|
| Chassis Type | Industrial Tower with Wall-Mounting |
| Color | Black |
Expansion Configuration
| PCI | None |
|---|---|
| PCIex16 | 2x PCIex16 3.0 (one at x16, or two at x8 connection) |
| PCIex8 | None |
| PCIex4 | 2x PCIex4 3.0 |
| PCIex1 | 3x PCIex1 3.0 |
Processor
| CPU | 8th/9th Gen Xeon & Core i7, i5, i3 |
|---|---|
| CPU Socket | LGA1151 |
| Chipset | Intel C246 |
System Memory
| Standard RAM | 8 GB |
|---|---|
| Maximum RAM | 64 GB |
| RAM Type | DDR4 |
| RAM Socket | 4x 288-pin DIMM |
Hard Drive
| Hard Drive | 250GB SSD 512MB Cache SATA 6.0Gb/s |
|---|
Optical Drive
| Optical Drive | Optional DVDRW |
|---|
System Power
| Power Supply | 500W |
|---|---|
| Power Supply Type | PS2 |
| Power Input | 100/240 VAC Auto-Switching |
BIOS
| BIOS Type | AMI |
|---|---|
| TPM | Optional TPM2.0 module to enable TPM and vPro technologies |
Graphics
| GPU | Intel HD Graphics |
|---|---|
| GPU Interface | 1x VGA; 1x DVI-D; 1x HDMI (Triple display capable) |
| Resolution | VGA 1920×1080 @60Hz; DVI-D 1920×1080 @60Hz; HDMI-2k, 4k @60Hz |
Ethernet
| Ethernet Port 1 | 10/100/1000 Mbps with Intel I219LM |
|---|---|
| Ethernet Port 2 | 10/100/1000 Mbps with Intel I210AT |
USB
| USB 2.0 | 7x USB 2.0: 2x Front I/O; 6x via Internal Header; 1x Type A internal Connector |
|---|---|
| USB 3.0 | 6x USB 3.0: (4x on Rear I/O; 2x via Internal Headers connected to chassis front USB 3.0 ) |
I/O
| SATA | 8x SATA-600 |
|---|---|
| PS/2 | None |
| Serial | 2x COM RS-232 via Internal Headers |
| Audio | MIC-in / Line-out |
RAID
| RAID | 0, 1, 5, 10 RAID Onboard |
|---|
Chassis Characteristics
| Construction | Heavy Duty Steel |
|---|---|
| Drive Capacity | 1 x 5.25” drive bay, 2 x 3.5” HDD drive bays |
| Front Panel Controls | 1x Power On/Off; 1x System Reset |
| Expansion profile | Full Height, Full length Card Support With Hold Down Bracket |
| Mounting | Wall Mounting Brackets Included |
| Cooling Fans | 1 x 12cm DC fan with a removable filter |
| Operating Temperature | 0°C to +40°C (+32°F to +104°F) |
| Dimensions (W x D x H) | 196 ± 1.0mm (7.72″) (W) x 407.4 ± 1.0mm (16.04″) (D) x 330 ± 1.0mm (13″) (H) |
