Description
General
| Model | R760-4 |
|---|---|
| Chassis Type | Industrial Rackmount |
| Rack Units | 4U |
| Color | Black |
Expansion Configuration
| PCI | None |
|---|---|
| PCIex16 | 4x PCIex16 4.0 |
| PCIex8 | 2x PCIex8 4.0 |
| PCIex4 | None |
| PCIex1 | None |
Processor
| CPU | 3rd Generation Intel® Xeon® Scalable Processors, TDP support 270W |
|---|---|
| CPU Socket | Dual LGA4189 |
| CPU Cores | Up to 72 Cores |
| Chipset | Intel® C621A |
System Memory
| Standard RAM | 16GB |
|---|---|
| Maximum RAM |
1TB |
| RAM Type | DDR4 ECC RDIMM unbuffered |
| RAM Socket | 16x 288-pin DIMM |
Hard Drive
| SSD | 250GB SSD |
|---|
Optical Drive
| Optical Drive | Optional DVD-RW |
|---|
System Power
| Power Supply | 700W |
|---|---|
| Power Supply Type | PS2 |
| Power Input | 100/240 VAC Auto-Switching |
BIOS
| BIOS Type | AMI BIOS |
|---|
Graphics
| GPU | ASPEED AST2500 BMC |
|---|---|
| GPU Interface | 1x VGA (VGA connector is dedicated for IPMI) |
Ethernet
| Ethernet Port 1 |
1 x 10GbE Ethernet (Intel® X550-AT2) |
|---|---|
| Ethernet Port 2 |
1 x 10GbE Ethernet (Intel® X550-AT2) |
| Ethernet Port 3 |
1 x IPMI LAN via Intel® I210-AT (shared with BMC AST2500) |
USB
| USB 2.0 |
4x USB 2.0: 2x Front Chassis; 2x 180D TypeA onboard |
|---|---|
| USB 3.2 |
6x USB 3.2 GEN1 Ports: 4x Rear I/O, 2 x USB 3.2 GEN1 Via internal box header |
I/O
| SATA | 8x SATA3 (6 Gbps) ports |
|---|---|
| M.2 | 2x M.2 Interface PCI-E 4.0 x4 (NVMe) RAID 0, 1 supported. |
| PS/2 | 1x PS/2 Keyboard (Internal Box Header) |
| Serial | 1x RS-232/422/485 Rear I/O |
| TPM | TPM 2.0 (Optional Via Onboard Header) |
| Audio | N/A |
| Digital IO |
8-channel programmable |
RAID
| RAID | SATA RAID 0,1,5,10 |
|---|
Chassis Characteristics
| Construction | Heavy-Duty Cold-Rolled Steel |
|---|---|
| Drive Capacity | 3 x 5.25″ (External); 1x 3.5″ (External); 4x 3.5″ (Internal); 1x Slim ODD |
| Front Panel Indicators | 1x Power On/Off; 1x HDD; 2x LAN Activity |
| Front Panel Controls | 1x Power On/Off; 1x System Reset |
| Front Door |
Thumb switch w/ Key Lock |
| Cooling Fans | 1x 120mm Front, 2x 80mm Rear |
| Power Options |
PS/2 Single ATX Supply and Redundant Option |
| Dimensions (D x W x H) | 563.7 x 430.0 x 176.0 (mm); 22.19″ x 16.93″ x 6.93″ (in) |
