Description
General
| Model | R709-4 |
|---|---|
| Chassis Type | Industrial Rackmount |
| Rack Units | 4U |
| Color | Black |
Expansion Configuration
| PCI | 2 x PCI (32-bit/33Mhz) |
|---|---|
| PCIex16 | 1 x PCIex16 5.0 |
| PCIex8 | None |
| PCIex4 | 3 x PCIex4 4.0 (x2 Link) |
| PCIex1 | None |
| PCIe Mini Card Slot |
None |
| M.2 Slot |
None |
| SIM Socket |
N/A |
Processor
| CPU | Intel® Core™ processors (Arrow Lake-S), up to 125W |
|---|---|
| CPU Socket | LGA1851 |
| Chipset | Intel W810 |
System Memory
| Standard RAM | 8 GB |
|---|---|
| Maximum RAM | 96 GB |
| RAM Type | DDR5 |
| RAM Socket | 2 x 288-pin Long-DIMM |
| Memory Support |
UDIMM Non-ECC |
Hard Drive
| SSD | 250GB SSD |
|---|
Optical Drive
| Optical Drive | Optional DVDRW |
|---|
System Power
| Power Supply | 500W |
|---|---|
| Power Supply Type | PS2 |
| Power Input | 100/240 VAC Auto-Switching |
BIOS Features
| BIOS Type | AMI SPI 256 Mbit |
|---|---|
| TPM | dTPM 2.0 |
| Watchdog Timer |
Programmable 1-255 sec |
Graphics
| GPU | Intel® Xe LPG Graphics |
|---|---|
| GPU Interface | 1 x HDMI 4.1 Max resolution up to 3840 x 2160 @ 30Hz
1 x VGA Max resolution up to 1920 x 1200 @ 60 Hz |
| Multi Display | Dual Display |
Ethernet
| Ethernet Port 1 | 1 x Intel® I219-V 10/100/1000 Mbps |
|---|---|
| Ethernet Port 2 | 1 x Intel®I226-V 10/100/1000/2500Mbps |
USB
| USB 2.0 | 6x USB 2.0 (2x to Front I/O, 2x Rear I/O, 2x Type-A internal) |
|---|---|
| USB 3.2 (Gen2) |
4 x USB 3.2 Gen1 (Rear I/O) |
I/O
| SATA | 4 x SATA3 (6Gb/s) |
|---|---|
| Serial | 2 x RS-232 on Rear I/O, 3 x RS-232 (Internal Box Header), 1x RS-232/422/485 (Internal Box Header) |
| Audio | High Definition Audio Line-Out, Mic-In |
| GPIO | 8-Bit GPIO header |
| PS/2 | N/A |
RAID
| RAID | Intel RAID 0, 1, 5, 10 |
|---|
Chassis Characteristics
| Construction | Heavy-Duty Cold-Rolled Steel |
|---|---|
| Drive Capacity | 3 x 5.25″ (External); 1x 3.5″ (External); 1x 3.5″ (Internal) |
| Front Panel Indicators | 1 x Power On/Off; 1x HDD |
| Front Panel Controls | 1 x Power On/Off; 1x System Reset |
| Cooling Fans | 1 x 12cm (In-flow direction) |
| Operating Temperature | -20°C – 70°C (-4°F – 158°F) |
| Dimensions (W x D x H) | 19″ (482.6mm) x 17.7″ (450mm) x 7″ (177mm) |
