Description
General
| Model | KVD083 |
|---|---|
| Mounting | Rackmount |
| Rack Units | 1U |
| Color | Black |
| Touchpad | Yes |
| Interface | USB/PS2 Combo |
| Keys | 104-Key Keyboard |
| Cable | 8x 6′ KVM Cables |
LCD Characteristics
| LCD Size | 17″ |
|---|---|
| Active Area (W x H) | 13.3″ (338 mm) x 10.6″ (270 mm) |
| Resolution | 1280 x 1024 |
| Brightness (cd / m²) | 250 |
| Contrast | 1000 : 1 |
| Backlight | CCFL |
| Viewing Angle (H / V) | 160° / 160° |
System Power
| Power Supply Type | AC PSU Auto-Switching |
|---|---|
| Power Input | 100~240VAC (50/60Hz) |
| Power Consumption | 5 W (standby); 48 W (max) |
I/O
| PS/2 | Integrated Keyboard and Touchpad Mouse |
|---|
Chassis Characteristics
| Input Signal | VGA |
|---|---|
| MTBF | 50,000 hours |
| Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
| Non-Operating Temperature | -5°C ~ 60°C (23°F ~ 140°F) |
| Relative Humidity | 5% ~ 90% (Non-Condensing) |
| Shock Resistance | 10G |
| Vibration Resistance | 5 – 500 Hz, 1G |
| Dimensions (W x D x H) | 17.4″ (441.6mm) x 18.1″ (460mm) x 1.73″ (44mm) |
