Description
General
| Model | T530 |
|---|---|
| Chassis Type | Industrial ATX Tower with Wall-Mounting |
| Color | Black |
Expansion Configuration
| PCI | 1 x PCI |
|---|---|
| PCIex16 | 2 x PCIex16 3.0, (Slot 1 Running at x16/x8 signal) (Slot 2 Running at x0 or x8 signal) |
| PCIex8 | None |
| PCIex4 | 4 x PCIex4 3.0 Open ended (3 Slots running at x4 signal, 1 slot running at x1 signal) |
| PCIex1 | None |
| M.2 Slot 1 |
M.2 Key M 2280 with PCIe x4/SATA signal |
Processor
| CPU | 10th/11th Gen Xeon, Core i9 i7, i5, i3 Processors (Up to 125w TDP) |
|---|---|
| CPU Socket | LGA1200 |
| Chipset | Intel W480E |
System Memory
| Standard RAM | 8 GB |
|---|---|
| Maximum RAM | 128 GB |
| RAM Type | DDR4 |
| RAM Socket | 4x 288-pin DIMM |
| Memory Support |
UDIMM ECC (with Xeon processor) or Non-ECC |
Hard Drive
| SSD | 250GB SSD |
|---|
Optical Drive
| Optical Drive | Optional DVDRW |
|---|
System Power
| Power Supply | 500W |
|---|---|
| Power Supply Type | PS2 |
| Power Input | 100/240 VAC Auto-Switching |
BIOS Features
| BIOS Type | AMI BIOS |
|---|---|
| TPM | 1 x TPM 2.0 Header |
| Power Settings |
Wake on LAN |
Graphics
| GPU | Intel UHD Graphics |
|---|---|
| GPU Interface | 1 x DisplayPort++, 1 x HDMI, 1 x DVI-D, 1 x VGA. (Triple display Capable) |
Ethernet
| Ethernet Port 1 | 1 x 10/100/1000 Mbps Ethernet with Intel® i219-LM; supports Wake-on-LAN, PXE Boot ROM, iAMT |
|---|---|
| Ethernet Port 2 | 1 x 10/100/1000 Mbps Ethernet with Intel® i211-AT; supports Wake-on-LAN, PXE Boot ROM |
USB
| USB 2.0 | 2 x USB 2.0 (internal, 180D type A), 4 x USB 2.0 (internal, pin header), 2x 2.0 Routed to front I/O |
|---|---|
| USB 3.2 (Gen2) |
2 x USB 3.2 Gen2 (rear I/O) |
| USB 3.2 (Gen1) |
2 x USB 3.2 Gen1 (rear I/O), 2 x USB 3.2 Gen1 (internal, box header) |
I/O
| SATA | 4 x SATA-600 |
|---|---|
| Serial | 2 x RS-232/422/485 (rear I/O), 2 x RS-232 (Internal box header) |
| Audio | HD Codec audio as MIC-in/Line-in/Line-out |
| DIO | 8-channel programmable |
| PS/2 | 1 x PS/2 keyboard (internal box header) |
RAID
| RAID | SATA RAID 0/1/5/10 |
|---|
Chassis Characteristics
| Construction | Heavy Duty Steel |
|---|---|
| Drive Capacity | 1 x 5.25” drive bay, 2 x 3.5” HDD drive bays |
| Front Panel Controls | 1x Power On/Off; 1x System Reset |
| Expansion profile | Full Height, Full length Card Support With Hold Down Bracket |
| Mounting | Wall Mounting Brackets Included |
| Cooling Fans | 1 x 12cm DC fan with a removable filter |
| Operating Temperature | 0°C to +40°C (+32°F to +104°F) |
| Dimensions (W x D x H) | 196 ± 1.0mm (7.72″) (W) x 407.4 ± 1.0mm (16.04″) (D) x 330 ± 1.0mm (13″) (H) |
