Description
General
| Model | SHB150-109 |
|---|---|
| Chassis Type | Industrial Microbox |
| Color | Black |
Expansion
| ISA | None |
|---|---|
| PCI | None |
| PCIex16 | 1x PCIex16 |
| PCIex8 | None |
| PCIex4 | None |
| PCIex1 | 3x PCIex1 |
| PCI-X | None |
Processor
| CPU | 8th/9th Gen Core i7, i5, i3 |
|---|---|
| CPU Socket | LGA1151 |
| Chipset | Intel Q370 |
System Memory
| Standard RAM | 8 GB |
|---|---|
| Maximum RAM | 64 GB |
| RAM Type | DDR4 |
| RAM Socket | 2x 288-pin DDR4-2133/2400 un-buffered DIMM |
Hard Drive
| SSD | 250GB SSD |
|---|
Optical Drive
| Optical Drive | DVDRW |
|---|
System Power
| Power Supply | 500W |
|---|---|
| Power Supply Type | PS2 |
| Power Input | 100/240 VAC Auto-Switching |
BIOS
| BIOS Type | AMI |
|---|
Graphics
| GPU | Intel HD Graphics |
|---|---|
| GPU Interface | 1x DVI-I (Optional DVI-I to DVI-D+VGA Y cable for dual output) |
Ethernet
| Ethernet Port 1 | 1 x 10/100/1000 Mbps (Intel® i219-LM) |
|---|---|
| Ethernet Port 2 | 1 x 10/100/1000 Mbps (Intel® i211-AT) |
USB
| USB 2.0 | 10 x USB 2.0 (2x front accessible, 8x internal header) |
|---|---|
| USB 3.1 | 2 x USB 3.1 Gen2, 4 x USB 3.1 Gen1 (2x rear accessible, 2x internal header) |
I/O
| SATA | 6x SATA-600 |
|---|---|
| PS/2 | 1x Keyboard; 1x Mouse (Via Optional internal header) |
| Serial | 4x COM: 2x RS-232/422/485, 2x RS-232, All via Internal Headers |
| Parallel | 1x LPT via Internal Header |
| Audio | MIC-in / Line-in / Line-out (Via Optional Audio I/O Bracket) |
RAID
| RAID | 0, 1, 5, 10 RAID Onboard |
|---|
Chassis Characteristics
| Construction | Heavy-Duty Cold-Rolled Steel |
|---|---|
| Drive Capacity | 1x 5.25″ (External); 1x 3.5″ (External); 1x 3.5″ (Internal) |
| Front Panel Indicators | 1x Power On/Off; 1x HDD |
| Front Panel Controls | 1x Power On/Off; 1x System Reset |
| Cooling Fans | 1x 9cm |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Dimensions (W x D x H) | 9.45″ (240.2 mm) x 15.8″ (401.4 mm) x 6.1″ (154.7 mm) |
