Description
General
| Model | R706-2 |
|---|---|
| Chassis Type | Industrial Rackmount |
| Rack Units | 2U |
| Color | Black |
Expansion Configuration
| ISA | None |
|---|---|
| PCI | 3x PCI |
| PCIex16 | None |
| PCIex8 | None |
| PCIex4 | None |
| PCIex1 | None |
| PCI-X | None |
Alternate Expansion Configuration
| ISA | None |
|---|---|
| PCI | 2x PCI |
| PCIex16 | 1x PCIex16 |
| PCIex8 | None |
| PCIex4 | None |
| PCIex1 | None |
| PCI-X | None |
Processor
| CPU | 8th/9th Gen Core i7, i5, i3 |
|---|---|
| CPU Socket | LGA1151 |
| Chipset | Intel H310 |
System Memory
| Standard RAM | 8 GB |
|---|---|
| Maximum RAM | 64 GB |
| RAM Type | DDR4 |
| RAM Socket | 2x 288-pin DIMM |
Hard Drive
| SSD | 250GB SSD |
|---|
Optical Drive
| Optical Drive | Optional DVDRW |
|---|
System Power
| Power Supply | 500W |
|---|---|
| Power Supply Type | PS2 |
| Power Input | 100/240 VAC Auto-Switching |
BIOS
| BIOS Type | AMI |
|---|
Graphics
| GPU | Intel HD Graphics |
|---|---|
| GPU Interface | 1x VGA; 1x DVI |
Ethernet
| Ethernet Port 1 | 10/100/1000 Mbps with Intel I219V |
|---|---|
| Ethernet Port 2 | 10/100/1000 Mbps with Intel I211AT |
USB
| USB 2.0 | 5x USB 2.0: 2x Front I/O; 2x Rear I/O; 1x Type A Connector |
|---|---|
| USB 3.0 | 4x USB 3.0: 2x Rear I/O; 2x Internal Headers |
I/O
| SATA | 4x SATA-600 |
|---|---|
| PS/2 | 1x Keyboard; 1x Mouse |
| Serial | 6x COM: 2x RS-232 Rear I/O; 3x RS-232, 1x RS-232/422/485 Internal Headers |
| Audio | MIC-in / Line-out |
RAID
| RAID | Onboard N/A. PCIe Card required (optional) |
|---|
Chassis Characteristics
| Construction | Heavy-Duty Cold-Rolled Steel |
|---|---|
| Drive Capacity | 1x 5.25″ (External); 1x 3.5″ (External); 2x 3.5″ (Internal) |
| TPM | Optional TPM 2.0 |
| Front Panel Indicators | 1x Power On/Off; 1x HDD |
| Front Panel Controls | 1x Power On/Off; 1x System Reset |
| Cooling Fans | 1x 8cm |
| Watchdog Timer | 1 ~ 255 sec. |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Dimensions (W x D x H) | 19″ (482.6mm) x 17.7″ (450mm) x 3.5″ (88.9mm) |
