Description
General
| Model | EXB300 |
|---|---|
| Mounting | Wall mount |
| Color | White |
Expansion Configuration
| PCI | None |
|---|---|
| PCIe | 1x Full-size PCIe Mini Card |
| Expansion Slots | 1x SIM Card; 2x Antenna |
Processor
| CPU | Intel Atom E3815 1.46 GHz |
|---|---|
| CPU Socket | FCBGA1170 |
| Chipset | SoC Integrated |
System Memory
| Standard RAM | 2GB |
|---|---|
| Maximum RAM | 4GB |
| RAM Type | DDR3L |
| RAM Socket | 1x 204-pin SO-DIMM |
Hard Drive
| Hard Drive | 250 GB |
|---|
System Power
| Adapter | DC-in Terminal Block Connector |
|---|---|
| Power Input | 12 ~ 24VDC |
BIOS
| BIOS Type | AMI UEFI |
|---|
Graphics
| GPU Interface | 1x VGA |
|---|
USB
| USB 2.0 | 2x USB 2.0: 2x Front I/O |
|---|
I/O
| Digital I/O | 1x Isolated DI/DO (8-Bit Programmable) Optional |
|---|---|
| Ethernet | 2x 10/100/1000 Mbps |
| Serial | 4x COM: 4x RS-232/422/485 Front I/O |
System Characteristics
| Construction | Aluminum Extrusion and Heavy-Duty Steel with IP40 Protection |
|---|---|
| Drive Capacity | 1x 2.5″ SATA (Internal); 1x Compact Flash or mSATA |
| Front Panel Indicators | 1x LED for System Power-On; 1x LED for System Active |
| Cooling Fans | None |
| Watchdog Timer | 255 levels, 1 ~ 255 sec. |
| Operating Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
| Non-Operating Temperature | -40°C ~ 85°C (-40°F ~ 185°F) |
| Relative Humidity | 10% ~ 95% |
| Vibration Resistance | 2G, 5 – 500 Hz |
| Dimensions (W x D x H) | 1.88″ (48 mm) x 4.33″ (110 mm) x 6.1″ (155 mm) |
Compliance
| Certification | CE; FCC |
|---|
